400 amp Meter Base Correct Wiring Diagram Important wiring information Consumer wires to straight (load) buss spades REMC wires to curved (line) buss spades Neutral wire buss spades #4 copper to ground rod spade Meter base ground must be unbroken from ground rod to ground connection in base. Ground wire must be in 1/2” thin wall conduit or
